DIAMANT SMART PRO USE: INDUSTRIAL PLANTS, AUTOMATION SYSTEMS, HEATING / COOLING AND SANITARY WATER TORQUE: 11 Nm POSITIONING FEEDBACK 2-10V FAIL SAFE TWO EXTRA MICRO SWITCHES COMMUNICATION VIA WI-FI OR MODBUS-RTU INGRESS PROTECTION: IP67 MANUAL OPENING SMART PRO multifunctional actuators use the last generation stepper motors with closed loop control system: the position of the gear shaft is detected by a potentiometer and this grants high precision and reliability in terms of positioning. All SMART PRO actuators can be supplied with a Fail Safe system: in case of failure of power supply the actuator automatically moves to the set safety position by using the energy stored in the integrated supercapacitors. Thanks to the Wi-Fi configuration unit it is possible to easily and remotely access to ail actuator’s functions (type of control. operating times, rotation angles, etc), to check its status (reached position, inside temperature, work time. etc) and to perform a diagnostic control in case of mistakes or default. Versions with Modbus RTU can be connected to a RS485 2-wire network for the direct communication to a PLC or B MS by using the Modbus RTU protocol. This allows an easy and safe control and monitoring of the actuators.
Технические характеристики
CharacteristicsTypeelectricMovementquarter-turn, 90°, 180°TechnologystepperProtection classIP67Other characteristicsmodulating, compact, ball, for butterfly valves, adjustable, for control of shut-off, smart, low-noise level, remote-controlled, wireless, with backup battery, high-performance, with indicator, with integrated safety, variable-speed, bus-capable, three-position, with wireless remote control, with integrated limit switch, energy-efficientTorque
11 Nm (8.11 ft.lb)
Voltage
Max.: 240 V
Min.: 12 V
Ambient temperature
Max.: 50 °C (122 °F)
Min.: -10 °C (14 °F)
Rotation angle
90 °, 180 °
Operating time
15 s, 30 s, 60 s, 120 s
