LABEC Small Form Muffle Furnaces are a light-weight, compact solution for laboratories where space is limited. These universal furnaces are designed for material testing, heat treatment such as hardening, loosening, normalising, and ceramic and stoneware firing up to 1100°C. These furnaces are constructed of powder-coated steel exteriors with a one-piece high thermal efficiency vacuum formed ceramic fibre chamber, with heating elements embedded within four sides. All models feature a lift up safety door with safety cutoff when the door is opened during operation, and ceramic bottom plate. Microprocessor temperature control provides good stability and uniformity, and the low thermal mass construction ensures fast heating times and low power consumption.
Specifications:
Product ESF-3-SD
ESF-8-SD
ESF-13-SD
ESF-22-SD
ESF-39-SD
Capacity 3L 8.2L 13L 22L 39L Internal Dimensions 125 x 200 x 115mm 200 x 300 x 133mm 225 x 360 x 180mm 275 x 500 x 155mm 315 x 515 x 225mm External Dimensions 340 x 470 x 430mm 440 x 560 x 510mm 500 x 700 x 550mm 600 x 890 x 610mm 648 x 899 x 739mm Temperature Controller Digital PID Controller Temperature Range +300ºC to +1100ºC
Temperature Stability and Uniformity
±1ºC, ±10ºC
Construction Internal — Ceramic fibre muffle
External — Powder coated steel Safety Over temperature protection cut off, earth leakage breaker (ELB) Power Supply 240V 50Hz 415V 3-phase Power
(10A) 1700W 1800W 1800W 3000W 720W/10A/phase Weight 19kg 28kg 38kg 58kg 74kg
Optional:
ESF-Prog-E5CC-T Omron E5CC-T Programmable temperature controller
ESF-E3216-NP Eurotherm 3216 non-programmable temperature controller
ESF-E3216-PR Eurotherm 3208 programmable temperature controller
ESF-COMMS iTools PC connection and software
ESF-OTP-NA OTP Non-adjustable over temperature protection
ESF-OTP-ADJ OTP, Eurotherm 3216i Adjustable over temperature protection
ESF-TIME-D Timer Delayed furnace start
ESF-BUZZ Buzzer Audible signal
ESF-VENT-R Ventilation hole Ceramin tube, back side Ø17mm
ESF-CHIMNEY Chimney Non-fan-forced
ESF-WINDOW-35 Window Ø35mm window, temperature up to 1100C
ESF-GASPURG Gas injection system Argon or Nitrogen (flow meter, reducer and connections)
ESF-GASBOX Gas box Operate with protective gases (up to 1150C)
ESF-Extraction Extraction vent Fan-forced extraction vent
EYZ086 Tongs Furnace tongs, long
