The M-OTS-ST-410-12-I SmartTable® OTS™ Isolated Optical Table System combines the unmatched performance and value of our patented SmartTable optical table with a new, patent pending, isolation platform that features integrated accessories to optimize laboratory space, organization and safety. The system includes a 305 mm thick ST Series SmartTable with a 1200 mm width, 3000 mm length, and Metric M6 holes on a 25 mm grid. The M-OTS™ platform also integrates Newport»s I-800 pneumatic isolator design with a new rigid frame design to deliver an economical isolation platform with superior isolation performance and unmatched accessories. The I-800 isolator design has been used extensively by some of the world»s most demanding OEM customers who require a high performance, reliable and low cost of ownership solution. The SmartTable OTS optical table system is available with an exceptional offering of accessories to support any lab»s growing needs. All OTS systems come with casters as a standard feature for easy mobility.
Технические характеристики
- Tuned Damping 2 IQ Active Dampers
- Active Damping 2 IQ Active Dampers
- Broadband Damping Constrained layer core, damped working surface and composite edge finish
- Structural Damping Range 80-550 Hz
- Vibration Monitor Range 10-820 Hz
- Width 1200 mm
- Length 3000 mm
- Thickness 305 mm
- Working Surface Height 1034 ±12.5 mm
- Working Surface 4.8 mm thick 400 series ferromagnetic stainless steel
- Surface Flatness ±0.1 mm over 600 mm square
- Mounting Hole Type M6
- Mounting Hole Pattern 25 mm grid
- Mounting Hole Borders 12.5 mm
- Alphanumeric Grid Labels Yes
- Hole Sealing Type Easy clean non-corrosive high impact polymer conical cup, 19 mm deep
- Core Design Trussed honeycomb, vertically bonded closed cell construction, 0.25 mm steel sheet materials, 0.76 mm triple core interface
- Bottom Skin Material 4.8 mm thick carbon steel
- Horizontal Isolation, Res. 1.9 Hz
- Horizontal Amplification at Resonance 12.5 dB
- Horizontal Isolation, 5 Hz 80%
- Horizontal Isolation, 10 Hz 94%
- Vertical Isolation, Res. 1.7 Hz
- Vertical Amplification at Resonance 15 dB
- Vertical Isolation, 5 Hz 86%
- Vertical Isolation, 10 Hz 96%
- Load Capacity per Isolator 363 kg
- Maximum Payload 916 kg
- Weight — Tabletop 536 kg
- Weight — System 665 kg
- Crated Weight — Tabletop 650 kg
- Crated Weight — System 820 kg
- Frame Assembly Height 729 ±12.5 mm
- Maximum Air Pressure 5.8 Bar
