Single phase, F class, S1 duty service, IP55 Motive motors are built according to international standard regulations, each size throughout the construction forms is calculated with reference to the tables of standard IEC 72-1. The frame is made in die casting aluminium alloy. All MONO motors are single phase 230V 50Hz. On request 60Hz and special voltages F class insulation, (H on request) S1 continuous duty service, IP55 protection (IP56, 66 and 67 on request) on request extra capacitor for high starting torque The special winding permits a good starting torque even without a double capacitor start/run Aiming the maximum protection, the motors are equipped with important details like the pull-resistant cable gland and the combination of bearings with two shields each with rubber seal rings. Feet are detachable, and can be fixed on 3 sides of the housing, thus permittig the terminal box to be positioned up, right or left. Bearings selected for their silence and reliability and, for the same objectives, the rotor is dynamically balanced. The connection box can be rotated. Also available in self-braking version MADE IN ITALY
Технические характеристики
CharacteristicsAC/DCsingle-phaseTypeasynchronousVoltage 230 VProtection classIP55, IP56Configurationcapacitor, self-brakingNumber of polesmultipoleApplicationsindustrialPower
Max.: 4 kW (5.438 hp)
Min.: 0.18 kW (0.245 hp)
Torque
Max.: 26.33 Nm (19.42 ft.lb)
Min.: 0.61 Nm (0.4499 ft.lb)
Rotational speed
Max.: 2,916 rpm (18,321.77 rad.min-1)
Min.: 1,382 rpm (8,683.36 rad.min-1)
