Sick VS/VE18-4N3140V
Datasheet:
- Article: 6035500
- Sensor/detection principle: Single-pass sensor (cross-beam)
- Dimensions (W x H x D): 18 mm x 18 mm x 83 mm
- Housing shape (light output): Cylindrical
- Housing length: 83 mm
- Thread diameter (housing): M18 x 1
- Optical axis: Axial
- Operating distance, max.: 0 m … 20 m
- Sensing distance: 0 m … 18 m
- Focus: 2.5°
- Type of radiation: Infrared light
- RADIATION SOURCE: LED
- Light spot size (distance): Ш 600 mm (15 m)
- Emission angle: 2.5°
- Wavelength: 880 nm
- Adjustment: None
- Special applications: Hygienic areas and areas with high humidity
- Supply voltage: 10 V DC … 30 V DC
- Residual ripple: ± 10%
- Current consumption, transmitter: 35 mA
- Current consumption, receiver: 40 mA
- Switching output: NPN
- Switching type: LIGHT/DARK
- Switching type optional: Optional via control cable L/D
- Signal voltage NPN HIGH/LOW: Approx. UV/
- Output current Imax: ? 100 mA
- Rating: ? 2 ms
- Frequency switching: 250 Hz
- Reception angle: 8°
- Damping along the beam path: ? 20%
- Connection type: M12 connector, 4-pin.
- Protection schemes: A , B , C , D ,
- Protection class: III
- Weight: 240 g
- Case material: Stainless steel, Stainless steel V4A (1.4404, 316L)
- Material, optics: Plastic, Plan, PPS (Grilamid)
- Protection type: IP67, IP68, IP69K,
- Test input, transmitter off: TE after 0 V
- Temperature range during operation: –25 °C … +80 °C
- Temperature range during storage: – 40 °C … +80 °C
- UL File No.: FDA, UL No. NRKH.E181493 & cUL No. NRKH7.E181493
- Series:V18V
- Sensing distance:0 … 18 m
- Output type:NPN
- Type of radiation: infrared light
