Технические характеристики
| Photosensitive area | 2 × 3.3 mm |
|---|---|
| Number of elements | 1 |
| Package | Plastic |
| Cooling | Non-cooled |
| Reverse voltage (max.) | 20 V |
| Spectral response range | 760 to 1100 nm |
| Peak sensitivity wavelength (typ.) | 960 nm |
| Photosensitivity (typ.) | 0.68 A/W |
| Dark current (max.) | 2000 pA |
| Cutoff frequency (typ.) | 25 MHz |
| Terminal capacitance (typ.) | 16 pF |
| Noise equivalent power (typ.) | 1.2×10-14 W/Hz1/2 |
| Measurement condition | Ta=25 ℃, Typ., Photosensitivity: λ=780 nm, Dark current: VR=5 V, Cutoff frequency: VR=5 V, Terminal capacitance: VR=5 V, f=1 MHz, λ=λp, Noise equivalent power: λ=λp, unless otherwise noted |
