Технические характеристики
| Photosensitive area | φ0.8 mm |
|---|---|
| Number of elements | 1 |
| Package | Glass epoxy |
| Package category | Surface mount type |
| Cooling | Non-cooled |
| Reverse voltage (max.) | 20 V |
| Spectral response range | 380 to 1000 nm |
| Peak sensitivity wavelength (typ.) | 920 nm |
| Photosensitivity (typ.) | 0.64 A/W |
| Dark current (max.) | 500 pA |
| Cutoff frequency (typ.) | 100 MHz |
| Terminal capacitance (typ.) | 2 pF |
| Noise equivalent power (typ.) | 9.2 × 10-15 W/Hz1/2 |
| Measurement condition | Ta=25 ℃, Typ., Photosensitivity: λ=λp, Dark current: VR=10 V, Cutoff frequency: VR=10 V, RL=50 Ω,-3 dB Terminal capacitance: λ=830 nm VR=10 V, f=10 MHz, unless otherwise noted |
