Технические характеристики
| Element size (per 1 element) | 0.9 × 4.4 mm |
|---|---|
| Number of elements | 46 |
| Package | Ceramic |
| Package category | 48pin-DIP |
| Scintillator type | None |
| Cooling | Non-cooled |
| Reverse voltage (max.) | 15 V |
| Spectral response range | 190 to 1100 nm |
| Peak sensitivity wavelength (typ.) | 960 nm |
| Photosensitivity (typ.) | 0.58 A/W |
| Dark current (max.) | 10 pA |
| Rise time (typ.) | 1.2 μs |
| Terminal capacitance (typ.) | 550 pF |
| Measurement condition | Typ. Ta=25 ℃, unless otherwise noted per one element, Photosensitivity: λ=960 nm, Dark current: VR=10 mV, Rise time: VR=0 V, Terminal capacitance: VR=0 V |
