Scale reticles for measuring magnifiers, 7x (26mm), 10x (35mm) and 15x (26mm).
Specifications of reticle No.4:
- Degrees: 0-90° (one 10° area marked in 1° intervals)
- Scale: ± 0 to 10mm (0.1mm divisions)
- Squares: 5 x 10mm (0.1mm divisions)
- Circles: 0.1 to 1.0mm diameter (0.1mm divisions)
- Radius: 0-90° (0.1 and 0.5mm divisions)
Note: All reticles with the correct diameter can be fitted to magnifiers for special sizing purposes but high-power magnifiers have a limited field-of-view. The 30x magnifier (which uses a 26mm reticle) «sees» only 7mm and therefore these special reticules would rarely be of use.
Divisions of straight scales:
- No. 1 — Length 20mm, divisions 0.1mm
- No. 2 — Length 1mm, divisions 0.05mm. Length 20mm, divisions 0.1mm
- No. 8 — Length 20mm, divisions 0.1mm
Технические характеристики
O22-07-04
