Технические характеристики
- Wavelength Region VIS
- Wavelength Range 485-700 nm
- Mirror Shape Round
- Diameter 25.4 mm
- Mirror Size Ø25.4 mm
- Thickness 6.35 mm
- Material UV Grade Fused Silica
- Coating Type Broadband IBS Coating
- Coating Code SB.1
- Surface Quality 20-10 scratch-dig (10-5 in central 50%)
- Surface Flatness &lambda,/10 at 632.8 nm
- Wedge 30 ±15 arc min
- Angle of Incidence 0-15°
- Clear Aperture &ge,central 50% of diameter
- Back Surface Commercial Polish
- Reflectivity Rs, Rp>99.9% @ 485-700 nm
- Diameter Tolerance +0/-0.1 mm
- Thickness Tolerance ±0.38 mm
- Chamfers ±0.25 mm
- Chamfers Angle Tolerance 45° ± 15°
- Cleaning How to clean Supermirrors
