Технические характеристики
| Assembly Size | 30 mm x 30 mm |
|---|---|
| PMT Tube Size | — |
| Built-in PMT Type No. | R7600-00-M64 |
| Photocathode Area Shape | Square |
| Photocathode Area Size | 2 mm x 2 mm x 64 ch |
| Wavelength (Short) | 300 nm |
| Wavelength (Long) | 650 nm |
| Wavelength (Peak) | 420 nm |
| Spectral Response Curve Code | 400 K |
| Photocathode Material | Bialkali |
| Window Material | Borosilicate glass |
| Dynode Structure | Metal channel |
| Dynode Stages | 12 |
| [Max. Rating] Anode to Cathode Voltage | -1000 V |
| [Max. Rating] Average Anode Current | 0.45 mA |
| Anode to Cathode Supply Voltage | -800 V |
| [Cathode] Luminous Sensitivity Min. | 60 μA/lm |
| [Cathode] Luminous Sensitivity Typ. | 80 μA/lm |
| [Cathode] Blue Sensitivity Index (CS 5-58) Typ. | 9.5 |
| [Cathode] Radiant Sensitivity Typ. | 80 mA/W |
| [Anode] Luminous Sensitivity Min. | 10 A/lm |
| [Anode] Luminous Sensitivity Typ. | 50 A/lm |
| [Anode] Radiant Sensitivity Typ. | 5.0 x 104 A/W |
| [Anode] Gain Typ. | 6.3 x 105 |
| [Anode] Dark Current (after 30min.) Typ. | 0.2 nA /ch |
| [Anode] Dark Current (after 30min.) Max. | 2 nA /ch |
| [Time Response] Rise Time Typ. | 1 ns |
| [Time Response] Transit Time Typ. | 12 ns |
| [Time Response] Transit Time Spread Typ. | 0.38 ns |
| [Anode] Pulse Linearity (2% deviation) | 0.3 mA /ch |
| [Anode] Pulse Linearity (5% deviation) | 0.6 mA /ch |
