The positive-locking, disengaging torque limiting clutch according to the ball-recess principle. During operation, the set torque is transmitted from the hub via the pressure flange or the flange hub to the output. If the set torque is exceeded (overload case), the clutch disengages. During disengagement, the pins in the overload elements perform an axial movement (stroke) and remain in the disengaged position. Trailing masses can run out freely. Re-engagement takes place manually. Product features Application At high speeds Test benches Behavior on overload load-break Design Positive locking unlocking Re-engagement Remotely or manually operated re-engagement Benefits Free run out High power density High torsional stiffness Completely assembled balanced
Технические характеристики
CharacteristicsOperationmechanical, magneticOther characteristicssafety, load-separating, zero-backlash, with couplingTorque
Max.: 11,200 Nm (8,260.6961 ft.lb)
Min.: 45 Nm (33.1903 ft.lb)
Rotational speed
Max.: 25,000 rpm (157,079.63 rad.min-1)
Min.: 8,000 rpm (50,265.48 rad.min-1)
