Manual/Servo control modes provide the clinician more flexibility while optimizing the thermal environment. In addition, the skin / Air temperature display is larger than the other set temperature display. Skin temperature can be converted from Celsius to Fahrenheit by the push of a button. The spacious baby bed incorporates easy drop down sides for maximum access to the baby.
Features of Tiana IRW1723:
Advance microprocessor controlled system with self-checking of the skin/air manual electronic circuitry. Digital display of baby temperature.
The control panel is also the core of a fully integrated alarm system with audible as well as visual indicators —
• Probe fail • Skin High • Skin Low
• Power Fail • Heater Fail
Manual Mode:
Facility to convert the warmer from the servo mode to the unit’s manual mode.
Heater Assembly:
The heater assembly located above the centre of the support structure consists of an integral examination light and a 650 watts heating system (Silica or quartz /Ceramic Heater) for quick warming and even distribution of heat on the baby bed. The heater can be swivelled in either direction for taking X-rays and doing procedures.
Castors:
The system is equipped with 4 ‘high-quality castors with front 2 castors brakes, Antistatic castors(Optional)
Product Specification
Dimensions
Technical Specification:-
Height — 1850mm
Length — 1050mm
Width — 650mm
Electrical Specification (IEC complaint) :-
Power supply — 200V / 50Htz
Heater Power — 650 Watts
Fuse — 5 Amp.
Highlight of the product
The unit is designed in such a way that the main control system can be swivelled to the other side for access from all the four sides to the patient in critical condition. Option: weighing scale
