Description
The Rotronic CF5 Series CO2 / Temperature Transmitters measure CO2 concentration within the range of 0 to 2000ppm as well as temperature within the range of 32 to 122°F (0 to 50°C). The CF5 has 2 analog outputs: one for CO2 concentration and the other for temperature. Each output can be configured for a signal type of 0 to 10VDC, 2 to 10VDC or 4 to 20mA.
Applications for ventilation control in:
- Residential properties
- Offices
- Classrooms
- Cinemas
- Hospitals
Технические характеристики
Features
- Measurement ranges:
- CO2, 0 to 3,000 ppm
- Temperature, 30 to 120°F (0 to 50 °C)
- Measurement technique: Non-Dispersive InfraRed (NDIR) with automatic calibration
- Accuracy: ±30 ppm
- Power supply: 16…29 VDC/AC
- Output 1 (0…2,000 ppm): 0/2…10 VDC or 0/4…20 mA
- Output 2 (0…50 °C): 0/2…10 VDC or 0/4…20 mA
- Range of application: 0…50 °C (30…120 °F) / 0…95 %RH
- Maintenance: not necessary
- Lifetime: >15 years
