This low frequency preamplifier will provide reliable, repeatable measurements. An ideal solution and a standard workhorse of any EMC test house for compliance testing. Features 5 KHz to 300 MHz 30 dB Gain Low Noise, High Gain Rugged Construction Product Details A.H. Systems’ Preamplifier line is an excellent choice with a rugged design, no hassles with soldering your own power leads and they improve overall system sensitivity by at least 28 dB. All of A.H. Systems’ Preamplifiers come with a 12-volt DC regulated power source. A low voltage indicator confidently allows you to power the amplifier with your own external 12-volt DC battery. This makes it a convenient choice for field measurements. Antenna Specifications PAM-5K300 Preamplifier Frequency Range — 5 KHz — 300 MHz Gain (typical) — 32 dB Gain (minimum) — 28 dB Noise Figure — 2.1 dB Flatness — +/- 1 dB Input VSWR — less than 1.5 Output VSWR — less than 1.5 Input Power — 100/220 VAC regulated P/S output: 12 VDC 140 mA Connectors — N(f) to N(f)
Технические характеристики
CharacteristicsTypeRFSecondary functionmeasuringOther characteristicslow-noise, rugged, low-frequency, EMCVoltage
12 V
Current
100 mA
Frequency
Max.: 300,000 kHz
Min.: 5 kHz
