Characteristic of connection Crimp Color contact insert — blue Contact-Ø power — 3.6 mm Contact-Ø signal — 2 mm Crimp range — 0.14 – 16 mm² Degree of Protection — 3 External thread plug-in side M40 x 1,5 Flange — 40 x 40 mm Hole diameter — 4 x Ø 4,5 mm Hole distance — 30 mm Housing type — Panel Insert — Pin Installation type — Flange,Front wall Insulation resistance power — > 10^13 Ω Insulation resistance signal — > 10^13 Ω Length (L) — 51 mm Locking type — Screw connection Material housing — Zinc Die Cast Material housing surface — Nickel Material insulating body — PBT Material seals/o-rings FKM (FPM),NBR max. contact resistance power — 1 mOhm max. contact resistance signal — 3 mOhm Nominal current power — 55 A Nominal voltage at degree of pollution 3 power — 600 V~ Nominal voltage at degree of pollution 3 signal — 300 V~ Nominal current signal — 28 A Number of contacts PE — 1 Number of contacts power — 3 Number of contacts signal — 2 Number of poles — 6 Pole picture — 2 + 3 + PE Protection class — IP 67,IP 69 K Seal type — O-Ring Shield — unshielded Suitable PE-/FE-contacts — 7015953601, 7015953611, 7015953621, 7015953623, 7015953631 Suitable power contacts — 7015953601, 7015953611, 7015953621, 7015953622, 7015953631 Suitable Signal contacts — 7015952001 Temperature range — -40°C to +125°C Terminal cross section power — 2.5 – 16 mm² Terminal cross section signal — 1.5 – 1.5 mm² Test voltage power — 4000 V~ Test voltage signal — 2500 V~ Version — for pin inserts Minimum mating cycles — > 500 Panel hole — Ø 32 + 0,1 mm
Технические характеристики
CharacteristicsTypeRFFormatDINShapecircularConnection typecrimp, flange, plug-inSizeM40Electrical characteristicspowerProduct applicationsexternal threadProtection classIP67, IP69KOther characteristicsbuilt-inPrimary current
28 A, 55 A
Voltage
300 V, 600 V
