Featuring ResMed’s unique volume-assurance mode – iVAPS (intelligent Volume-Assured Pressure Support) – Lumis 150 Bipap VPAP ST maintains target level ventilation to suit each user’s changing needs. And with an intelligent Backup Rate (iBR) and optional AutoEPAP, iVAPS continuously monitors ventilation and the upper airway. The device is easy to set up and use and is supported by ResMed’s ResScan™ management software.

Key Features of ResMed BiPAP Machine Lumis 150:

iVAPS learns & sets appropriate targets, then provides smooth pressure support to suit.
intelligent Backup Rate (iBR) gives maximum opportunity to trigger the ventilator. Staying out of the way until needed, iBR adds backup breaths to comfortably bring the user back to target. (Available in iVAPS and ST modes)

AutoEPAP of ResMed Lumis 150 BiPAP maintains upper airway patency by auto-adjusting the expiratory pressure in response to partial and full obstructions. (Available in iVAPS mode)

Vsync provides excellent user–ventilator synchrony, even in the presence of a significant leak.

TiControl™ lets you set min and max limits on either side of the user’s ideal inspiratory time to encourage spontaneous breathing.

Trigger and cycle help you optimise settings according to the user’s condition, using five trigger and cycle sensitivity levels.

QuickNav for low-touch adjustment. By simply double-clicking the home button on the ResMed BiPAP Lumis 150, you can toggle between the Settings and Monitoring screens to change and check settings quickly and easily.

Climate Control Auto for automatic humidification. When BiPAP Lumis 150 is used with a HumidAir™ heated humidifier and ClimateLineAir™ heated tube, Lumis delivers humidification automatically – no settings to change and no complicated menus to navigate.

Ramp and Ramp Down for extra comfort. Lumis v pap machine offers both Ramp and Ramp Down features to help users ease into and out of each session.

ResScan software for advanced clinical insights. ResScan enables you to download your users’ data, change ventilator settings, and gain insight into their progress across a number of metrics (including AHI, leak and pressure). High-resolution data (at 25 Hz) is also available for breath-by-breath analysis and even greater insight.

ResMed BiPAP Machine Lumis 150 Includes:

BIPAP Device

Power Adapter & Cable

Tubing

Travel Bag

User Manuals

Specifications of ResMed Lumis 150 VPAP ST BiPAP Machine: BrandResMedModelLumis 150Usage/ApplicationHospitals & Personal UsePressure Range (cm H2O)2–25 cm H2O (2–25 hPa) in S, T, ST, PAC and iVAPS modes, 4–20 cm H2O (4–20 hPa) in CPAP modeSound/Noise Level (dB)26.6 dBA with uncertainty of 2 dBA as measured according to ISO 17510-1:2009 (CPAP mode)General System of ResMed Lumis 150 BiPAP: Dimensions116 mm x 205 mm x 150 mm (Device only), 116 mm x 255 mm x 150 mm (Device with HumidAir humidifier)Weight Without Humidifier1106 gWeight With Humidifier1268 gComfort Features of ResMed BiPAP Lumis 150: Operating Temperature+5°C to +35°COperating AltitudeSea level to 2,591 m, Air pressure range 1013 hPa to 738 hPaAdditional Details of ResMed BiPAP Machine Lumis 150: Operating ModeCPAP, S, T, ST with optional iBR, PAC, iVAPS with iBR and optional AutoEPAP90 W Power Supply UnitInput range: 100–240 V, 50-60 Hz, 57 VA (typical power consumption) 108 VA (peak power consumption)Housing ConstructionFlame retardant engineering thermoplasticSupplemental OxygenRecommended maximum flow: 15 L/min (CPAP, S, T, ST, PAC), 4 L/min (iVAPS)Standard Air FilterPolyester non-woven fibreTubingSlimLine and ClimateLineAir (15 mm), Standard (19 mm)Air Outlet22 mm air outlet complies with ISO 5356-1:2004ClassificationIEC 60601-1: 2006: Class II (double insulation), Type BF Ingress protection IP22Operating Humidity10–95% relative humidity, non-condensingStorage and Transport Temperature-20°C to +60°CStorage and Transport Humidity5–95% relative humidity, non-condensing Estimated Delivery: 4-5 Days Warranty :
