Accuracy ±0.5 % FSO BFSL Overload pressure 400 bar Burst pressure 750 bar Operating voltage Ub 18…30 VDC Interface IO-Link 1.1 Analog output Analog, voltage/Analog, current selectable 4…20 mA/0…10 V Switching output 2x PNP/NPN NO/NC selectable Connection Connector, M12x1-Male, 4-pin Process connection G 1/4′ (DIN 3852) Process connection material 1.4301 stainless steel Gasket, material FKM Housing material 1.4301 stainless steel PE, High-density polyethylene IP rating IP67, when threaded in Approval/Conformity CE UKCA cULus WEEE
Технические характеристики
CharacteristicsPressure typerelativeTechnologymembraneOutputanalog, IO-LinkElectrical connectionM12 connectorSupply voltage24 Vdc, 12 Vdc, 15VDCMountingthreadedProcess connectionG 1/4Protection levelIP67ApplicationsprocessOther characteristicsmalePressure range
Max.: 250 bar (3,625.94 psi)
Min.: 0 bar (0 psi)
Process temperature
Max.: 125 °C (257 °F)
Min.: -40 °C (-40 °F)
