Features —Intelligent control:： —HMI PLC control：Ergonomic touch screen, easy operation, high stability and low maintenance cost. —Process formula memory: According to the formulation and logic of different materials to set parameters, it can easily load the saved process formula from the formula storage system, to make the process simpler. —Remote diagnosis and data transfer: Combined with Bluetooth and modules, realize remote data transfer and monitor, fast diagnosis. —Preheating: Preheat the equipment in advance according to the formula, to save labor. —High security protection: ensure the security of personnel and equipment —Emergency protection (to stop the equipment during emergency) —Limit switch —Protective cover —High-speed transmission warning (yellow painting sign) —Lower energy consumption and higher production: —Rely on a special-design control program and process monitor to achieve lower energy consumption. —Higher production is obtained under the same equipment specification, increasing output, reducing energy consumption. —One-stop service:： —Provide a complete set of solutions: factory design, equipment and auxiliary machine, fast response service system (online + underline)
Технические характеристики
CharacteristicsApplicationsrecyclingTreated materialfor PVC, for PP, for ABS, for PE, for HDPE, for LDPE, for LLDPENumber of screwssingle-screwOther characteristicsflexibleOutput
800 kg/h (1,763.6981 lb/h)
Max.: 1,200 kg/h (2,645.5471 lb/h)
Min.: 150 kg/h (330.6934 lb/h)
Screw diameter
150 mm (5.9 in)
Max.: 185 mm (7.3 in)
Min.: 80 mm (3.1 in)
Screw length
2,520 mm (99 in)
Max.: 2,700 mm (106 in)
Min.: 1,440 mm (57 in)
Maximum speed
100 rpm (628 rad.min-1)
Max.: 150 rpm (942 rad.min-1)
Min.: 10 rpm (63 rad.min-1)
Torque
10 Nm (7 ft.lb)
Max.: 12 Nm (9 ft.lb)
Min.: 8 Nm (6 ft.lb)
Temperature
200 °C (392 °F)
Max.: 400 °C (752 °F)
Min.: 100 °C (212 °F)
Maximum pressure
10 bar (145 psi)
Max.: 15 bar (217.6 psi)
Min.: 5 bar (72.5 psi)
Overall length
3,000 mm (118 in)
Max.: 5,540 mm (218 in)
Min.: 840 mm (33 in)
Overall width
1,000 mm (39 in)
Max.: 1,500 mm (59 in)
Min.: 800 mm (31 in)
Total height
1,500 mm (59 in)
Max.: 2,000 mm (79 in)
Min.: 1,000 mm (39 in)
Weight
5,000 kg (11,023 lb)
Max.: 6,000 kg (13,228 lb)
Min.: 1,000 kg (2,205 lb)
Power
318 kW (432.36 hp)
Max.: 480 kW (652.62 hp)
Min.: 5 kW (6.8 hp)
