oil free nitrogen compressor for nitrogen generator Product Item：Z-100/5-25 silent working 24 hours heavy duty working CE and iso 9001 30 days for ETD time oil free nitrogen compressor for nitrogen generator factory parameters: 1. Principle: Oil-free reciprocating piston 2. Cooling type: air or water cooling 3. Power consumption: ≤55kw 4. Speed: 300-560rpm 5. Flow rate: ≤1000Nm3/h 6. Inspiratory pressure: 0-0.5Mpa 7. Exhaust pressure: ≤30Mpa 8. Compression level: 1-4 Main features of nitrogen generator oil free nitrogen compressor products: All oil-free lubrication is clean and non-polluting. High efficiency and low energy consumption. High reliability, continuous operation for 24 hours. The unit is air-cooled or water-cooled to reduce installation costs. Compact structure, low operating and maintenance costs. universal nitrogen compressor for beering dispensing for factoryparameters: Kinly note ,if you have oil free nitrogen compressor for nitrogen generator inquiry please tell us follows information when you send inquiry: *Compressor working medium: If single gas ,how many purity ? if mixed gas , what’s gas content lit ? *Suction pressure(gauge pressure): barg *Exhaust pressure(gauge pressure): barg *Flow rate per hour for compressor: (Nm3/hr): Compressor gas suction temperature ? Compressor working hours per day : hours Compressor working site altitude : m Environment temperature ℃: low three phase voltage and frequency :
Технические характеристики
CharacteristicsTechnologyreciprocatingTypenitrogenPower sourceelectrically-poweredPortabilitystationaryLubricationoil-freeOther characteristicscompact, low-noise, air-cooled, water-cooledPressure
Min.: 0 bar (0 psi)
Max.: 300 bar (4,351.13 psi)
Flow
Min.: 0 m³/h (0 ft³/h)
Max.: 1,000 m³/h (35,314.67 ft³/h)
Power
Min.: 0 kW (0 hp)
Max.: 55 kW (74.78 hp)
