Product Item：ow-20/4-8 silent working 24 hours heavy duty working CE and iso 9001 40 days for ETD time Category：Low Pressure Oxygen Compressor oilless medical oxygen compressor parameters: 1. Principle: Oil-free reciprocating piston 2. Cooling type: air or water cooling 3. Power consumption: ≤55kw 4. Speed: 300-560rpm 5. Flow rate: ≤800Nm3/h 6. Inspiratory pressure: 0-0.5Mpa 7. Exhaust pressure: ≤30Mpa 8. Compression level: 1-4 Main features of low pressure oilless oxygen compressor Devices products: All oil-free lubrication is clean and non-polluting. High efficiency and low energy consumption. High reliability, continuous operation for 24 hours. The unit is air-cooled or water-cooled to reduce installation costs. Compact structure, low operating and maintenance costs. Device parameters: 1. Principle: Oil-free reciprocating piston 2. Cooling type: air or water cooling 3. Power consumption: ≤55kw 4. Speed: 300-560rpm 5. Flow rate: ≤800Nm3/h 6. Inspiratory pressure: 0-0.5Mpa 7. Exhaust pressure: ≤30Mpa 8. Compression level: 1-4 Kinly note ,if you have low pressure oilless medical oxygen compressor inquiry please tell us follows information when you send inquiry: *Compressor working medium: If single gas ,how many purity ? if mixed gas , what’s gas content lit ? *Suction pressure(gauge pressure): barg *Exhaust pressure(gauge pressure): barg *Flow rate per hour for compressor: (Nm3/hr): Compressor gas suction temperature ? Compressor working hours per day : hours Compressor working site altitude : m Environment temperature ℃: low three phase voltage and frequency :
Технические характеристики
CharacteristicsTechnologyreciprocatingTypefor oxygenPower sourceelectrically-poweredPortabilitystationaryLubricationoil-freeApplication domainfor medical applicationsOther characteristicscompact, low-noise, high-efficiency, air-cooled, water-cooled, low-pressurePressure
Max.: 300 bar (4,351.13 psi)
Min.: 0 bar (0 psi)
Flow
Max.: 800 m³/h (28,251.73 ft³/h)
Min.: 0 m³/h (0 ft³/h)
Power
Max.: 55 kW (74.78 hp)
Min.: 0 kW (0 hp)
