Product Information Benefits Increase inspection productivity
- Parallel firing capability: QuartZ supports 32:128 or 2×16:64 configurations for two simultaneous apertures on one or two probes
- Integrated probe splitter: Connects two Phased Array probes without any additional accessories
- High Power Phased Array channels: QuartZ incorporates real 100V pulser for the Phased Array channels. Ideal for the inspection of very thick or difficult to penetrate materials
- Two powerful conventional UT channels: A full inspection configuration of two PA probes and two UT probes only needs one simple instrument
- High data throughput: QuartZ can deliver up to 30MB/s of data throughput making the difference for demanding applications
- Automatic probe detection: When using Zetec probes, QuartZ automatically detects the probe(s) the probes connected ensuring using the right probe and simplifying traceability up the reporting process
Simplify your inspection process through innovation
- Time Reversal Support: Allows inspecting various geometry changing surfaces of composite materials without complex surface following mechanics or previous knowledge of the exact part shape
Meet your specific needs, today and in the future
- UltraVision 3 ® Controlled: Tap into the full power of QuartZ. Offering a 3D work environment, UltraVision delivers the full inspection process within the same software package, from inspection design to advanced analysis and reporting.
- Scalable: Up to 10 QuartZ units in parallel controlled by the same UltraVision. Almost no inspection configuration is too big
- Easy Integration: Multiple QuartZ units can be synchronized in a simple cable configuration. Changing from table top to 19″» rack mount configuration is as simple as adding the included mounting brackets
- Made tough for harsh environments: QuartZ can be installed close to the probes, reducing cable length. No air conditioning is needed saving in project complexity and installation costs
SPECIFICATIONS QuartZ-Configuration Phased Array Channels 32:128 PR PA Firing Modes Up to 32 consecutive elements. Up to two apertures of 16 consecutive elements Phased Array Connector 2 x ZPAC connector (custom ZIF with latch). Allows connecting 2 probes without splitter. Automatic probe recognitions (with Zetec probes). UT Channels 2 channels (in Pulse/Echo or Pitch/Catch configurations Pulser Pulse width 25 ns to 500 ns Pulse amplitude PA (at 50Ω) 35 V to 100 V Pulse amplitude UT (at 50Ω) 50 V to 200 V Data Acquisition A-scan length Up to 16,384 points Maximum number of focal laws 1024 Real-time averaging 1, 2, 4, 8, and 16 Compression 1, 2, 4, 8, and 16 PRF Up to 20 kHz Parallel Firing 2 beams Maximum number of samples 16384 Measurement Gates 4 gates + 1 synchronization gate Data throughput Up to 30 MB/s Maximum data file 20 GB Digitizing frequency 25 MHz, 50 MHz or 100 MHz Bandwidth (at -3 dB) 500 kHz to 18 MHz Summed data amplitude resolution 16 bits Filters Analog / Digital band-pass, high-pass and low-pass Gain setting range PA 70 dB (analog) + 30 dB (digital) Gain setting range UT 70 dB (analog) + 24 dB (digital) Interfacing Data Interfaces Ethernet 1000 Base-T Encoder 2 axes (quadrature, clock direction) Housing Size (H × W × D) 420x490x90mm (16.5 x 19.3 x 3.5 in) Weight 8.34 Kg Air Intake No General specifications Voltage 120 VAC or 240 VAC Frequency 50 Hz or 60 Hz Maximum power 75 VA
