Compact hermetic pump for continuous dosage The micro annular gear pump mzr-7265 is suitable for handling crystallizing, oxygen or moisture sensitive liquids, because the pump has no shaft seal. This functionality is made possible thanks to a liquid-separating cup surrounding the magnetic drive. The compact dimension of this magnetic hermetic pump is achieved by a completely new product design and optimal matching with an integrated speed and position controller. The pump has a length of 84 mm and a weight of 580 g. The pump handles flow rates from 0,048 to 288 ml/min with a high precision and low pulsation. The pump is suitable for applications where an avoidance of leakage and a long service life as well as low energy consumption are important requirements. The pump is supplied with a terminal box for speed control and LED status indicator. Advantages Hermetic pump design pump without shaft seal Magnetic drive inner magnet system driven by rotating magnetic field Integrated motion controller programmable motion controller for speed and position control with RS-232 interface Compact dimensions length 84 mm
Технические характеристики
CharacteristicsOperationwith DC motor, magnetic-driveTechnologygearDomainindustrial, for the biotechnology industry, for marine applicationsApplicationshandling, metering, dischargeFluid specificationfor AdBlueOther characteristicscompact, adjustable, micro, programmableFlow
Min.: 0 l/min (0 us gal/min)
Max.: 0.288 l/min (0.07608 us gal/min)
Pressure
Min.: 0 bar (0 psi)
Max.: 15 bar (217.557 psi)
Power
21 W (0.03 hp)
