STANDARD EXECUTIONS — GN 565: aluminium, oval cross section bar. Threaded blind holes. — GN 565.1: aluminium, oval cross section bar. Pass-through holes for cylindrical-head screws with hexagon socket. — GN 565.5-A: AISI 304 stainless steel, oval cross section bar, sandblasted matte finish. Threaded blind holes. — GN 565.5-B: cast AISI CF-8 stainless steel, sandblasted matte finish. Pass-through holes for cylindrical-head screws with hexagon socket. Finish index for GN 565 and GN 565.1: — BL: natural aluminium, — EL: anodised aluminium, natural colour, matte finish. — SW: aluminium with epoxy resin coating, RAL 9005 black colour, matte finish, — SWU: aluminium with epoxy resin coating resistant to UV rays, RAL 9005 black colour, matte finish. — WSA: aluminium with antimicrobial epoxy resin coating, RAL 9002 white colour, matte finish. SPECIAL EXECUTIONS ON REQUEST — GN 565.5-A-GP: stainless steel fine-casting, glossy finish. — Lengths and colours other than the standard executions.
Технические характеристики
CharacteristicsTypepullApplicationsdoorMaterialstainless steelShapeovalSize
Min.: 100 mm (3.94 in)
Max.: 500 mm (19.69 in)
