PT 100 ohm at 0°C class B sensing element, inside a 316L stainless steel sheath, with sealed end and 3 wire PVC insulated cable with connection thimbles, with or without shielding. Temperature range: — 30 to + 90°C. Other manufacturing capabilities: accuracy from class A up to 1/10 class B .diameter 5 or 6 mm, total sheath length from 50 up to 1000 mm, other cable length, other types of electrical connections, 4 wires circuit.
Технические характеристики
CharacteristicsTechnologyPt100Protection levelwaterproofOther characteristicsstainless steel, 3-wire, 4-wire, insulatedTemperature
Min.: -30 °C (-22 °F)
Max.: 90 °C (194 °F)
Probe diameter
5 mm, 6 mm (0.2 in)
