Description
The ELx405 Select is the world»s first deep well microplate washer that aspirates and dispenses into 96- and 384-well plates without requiring specialized manifolds. ANSI/SBS standard height microplates can also be washed, making the ELx405 Select a total solution for all your laboratory»s microplate washing workflows. Wash processes used in cell culture and plasmid DNA preparation are automated with the ELx405 Select – there»s no need for specialized instrumentation. ELx405 Select can also process magnetic and polystyrene bead protocols, making it a versatile plate washer for many laboratories. The ELx405™ Select is automation compatible and its patented Dual-Action™ manifold is particularly useful in cell-based assays. This product is ideal for all standard and deep well microplate washing requirements.
Specification:
- Microplate types: 96- and 384-well, low profile and standard height, deep well plates up to 50 mm
- Onboard software: Create, edit or run multiple protocols
- Software (computer control): LHC2 pc software
- Shaking: Programmable up to 60 minutes (Slow, medium, fast or variable)
- Soaking: Programmable up to 60 minutes
- Automation: BioStack (for standard plate heights only) and 3rd party automation compatible (deep well and standard plates)
- Manifold types: 96-tube Dual-Action manifold for 96- & 384-well washing
- Volume range: 50 – 3000 µL/well, in 1 µL increments
- Wash cycles: 1-10
- Buffer/reagent selection: Auto switching module for up to 4 buffers (option)
- Supply bottle: 4 L or 10 L (optional)
- Dispense precision: ≤3% CV: 300 µL/well (96-well washing)
- Residual volume: <,2 µL/well (standard & deep well 96-well plates)
- Wash speed: 96-wells, 300 µL/well, 3 cycles (<,30 seconds), 384-wells,100 µL/well, 3 cycles (<,80 seconds)
- Flow rates: High flow to low flow, optimized rates for cell assays
- Sterilization: chemical
- Power: 100 – 240 Volts AC 50/60 Hz
- Dimensions: 14″ W x 17″ D x 11″ H (35.6 x 43.2 x 27.9 cm)
- Weight: 30 lbs (13.5 kg)
