Mitutoyo offers several software suites with a variety of features that power different Coordinate Measuring Machine applications. The software suites, when paired with the proper CMM probe, support surface measurements, vision measurements, point cloud data processing, and fully automatic measurement program generator from CAD models on CMMs.
| Order No.: | Software Product: | Product Description: | CMM Type: | Optional Software Modules: | Requirements: |
|---|
| Order No.: |
|---|
| 64AAB046 | MCOSMOS | Metrology suite of inter-related modules and dedicated expansion modules dedicated for specific applications such as CAD model programming, scanning, gear measurement, airfoil measurement | CNC Manual | CAT1000P CAT1000S Scanpak Gearpak MAFIS (Airfoil) | CMM+MCOSMOS |
| 64AAB448 | MiCAT PLANNER | Fully automatic measurement program generator from CAD model w/PMI for CMM»s with MCOSMOS | CNC | MICAT PLANNER V1.9, CATIA MICAT PLANNER V1.9, NX MICAT PLANNER V1.9, CREO MICAT PLANNER V1.9, SolidWorks MICAT PLANNER V1.9, STEP | CMM+MCOSMOS |
| 02NAA261 | MSURF | Point cloud data processing software performing measurement to evaluation with a suite of inter-related modules for specific applications such as CAD model programming, airfoil measurement, and surface meash generation | CNC | MSURF-S MSURF-I MSURF-I PRO MSURF-G MSURF-AFI (Air Foil Insp.) MSURF-Mesh PRO MSURF-Planner | CMM+MCOSMOS+Laser Probe |
| 02NBA621 | Visionpak | Measurement program for QVP equipped CMMs using image processing functions to detect edges at high speed, height measurement using auto-focus function, outlier removal function, and save captured images | CNC |
| CMM+QVP Probe |
| 12AAR775 | FORMTRACEPAK-AP | Surface roughness analysis software that conforms to ISO, JIS, ANSI, and VDA standards for comparing the measurement values with the tolerance limits, comes with parameter calculation functions, graphic analysis functions | CNC |
| CMM+SurfTest Probe |
