Product Information Features
- Largest and highest resolution display in it’s field, with built in reflectivity for sunlight readability.
- Enhanced Imaging Capability enables A-Scan, B-Scans and C-Scans.
- Full screen mode uses 100% of the display for the scan imaging with 29 layouts to choose from so data can be viewed and worked in any layout you wish.
- Numerous palettes are available for all scans – use amplitude or depth C-Scans. You can even customize palettes.
- Advanced display modes include smoothing, contouring, averaging, envelope….
- A-Scan resolution – up to 8192 points!
- Full data recording is possible including screen shots. This also aids traceability and can confirm repeatability.
- Probe & Wedge on-board database.
- New Configuration Wizard helps the technician to get the best out of the Prisma.
- Parameter Genius highlights the source of incorrect set ups by showing you the parameters that are not configured correctly.
- The TOFD option is on board – so no need to have extra instrumentation for TOFD Inspection.
- The Prisma is upgradeable – anytime and anywhere. So if TOFD or PA is required for the next project simply contact us to upgrade – in the field. No need to return your instrument.
- UT Studio analysis software is simple to use with powerful results, based on a drag and drop approach in an intuitive environment.
As simple as you want
- 30-second configuration
- No Delay UT to PA one button away
- Configuration and Calibration Wizards
- Parameter Genius giving you step by step assurance
- Minimize training due to the common user interface
- UT Studio+ provides fast & dynamic reporting
As capable as you need
- UT, TOFD & PA Inspection Modes
- Multi-mode validation of inspection
- Upgradeable anytime, anywhere!
- Unique cursors for precision measurement
- Recordability: screenshots, full data recording, fully traceable.
- Customizable imaging layout 29 to choose from.
prisma UT Standard Kit
Dual UT Channels with:
- A-Scan Recording
- 2 Axis Encoding
- Interface Triggering (IFT)
- A, B and C-Scan Displays
- USB Stick (8Gb)
- Couplant
- User Manual
- Quick User Guide
- 2 Point Neck Harness
- Lithium-Ion Battery Pack
- Power Cord & Power Supply adaptor
- Screen Protector (Anti-Glare)
- Transport Case (Airplane Carry on size)
prisma UT/PA 16/16 Standard Kit
Dual UT Channel kit
- A-Scan recording
- 2 Axis Encoding
- Interface Triggering (IFT)
- A, B and C Scan Displays
- USB Stick (8Gb)
- Couplant
- 16:16 Manual PA
- 2 Point Neck Harness
- Lithium-Ion Battery Pack
- Power Cord & Power Supply adaptor
- Screen Protector (Anti-Glare)
- Transport Case (Airplane Carry on size)
Software Options SW PRISMA PA 16:16 prisma Software 16:16 PA SW PRISMA PA 16:64 prisma Software 16:64 PA SW PRISMA TOFD prisma Software TOFD UT-STUDIO PA UT Studio+ Xpair Xpair Single License PA-INTEGRATOR PACK CSV Software Option
