The JBC TESE-2QB is a hot-air soldering station for precision work and repair of small and medium SMD components. The station consists of a control unit, hot-air tool and a tool stand. In addition to the standard manual mode, the station has a number of built-in profiles that enable rework tasks to be carried out with maximum precision. You can also create your own profiles with which the temperature and airflow values are controlled. By means of a thermocouple it is possible to achieve very precise temperature control of a component or PCB. Herewith it is also possible to protect certain parts or specific spots on a PCB against overheating.
At this station, the TE-TB hot air tool is supplied together with three straight, small nozzles. The tool stand detects when this rework tool is inserted into the holder and immediately activates the automatic rework tool’s standby mode. This stand-by mode ensures better workplace safety and longer life of the nozzles and hot-air tool. Furthermore, the stand also has a ‘quick nozzle changer’ which makes it possible to quickly and safely change nozzles, even if they’re still warm.
For a set which includes more accesories check out the TESE-2B.
If you are looking for a more powerful hot-air drive for more general purposes you might want to take a look at the JTSE-2B.
Specifications Power 300W Temperature range150-450 Air flow control 2-17 standard L/min Vacuum 30% Communication interfaceUSB-B ESD — safe yes Automatic standby yes Dimensions 148 x 184 x 140 mm Weight4.93 kg
Accessories The TESE-2QB hot air station comes standard with:
- TESE control unit
- TE-SE tool stand
- TE-TB hot-air tool
- Thermocouple (PH218)
- Power cord
- Manual
Options Pedal With this pedal the airflow of the hot-air station can be controlled. P-005 210 €210.00 Excl. VAT Info Add to Cart
