Drawing number 3521-25 Spacing washer to push-in cam see accessories Extensions 700 mm (length flexible) Fine adjusting range 7 mm Maximum adjustment load 150 kN Maximum torque 60 Nm Torque per 10 kN 4 Nm Hexagonal wrench for adjustment 17 mm Height adjustment per adjusting screw turn 0,375 mm Flexibility/rigidity 5000 N/µm Weight of wedge 7,4 kg
Технические характеристики
CharacteristicsApplicationsprecisionOther characteristicsadjustable, with extension
