Drawing number 3511-07 Dimension floor bolting M20 x 400 Kind of floor bolting Extension anchor bolt Alternativ floor bolting M24 x 500 Spacing washer to push-in cam see accessories Fine adjusting range 7 mm Maximum adjustment load 150 kN Maximum torque 60 Nm Torque per 10 kN 4 Nm Hexagonal wrench for adjustment 17 mm Height adjustment per adjusting screw turn 0,375 mm Flexibility/rigidity 5000 N/µm Weight of wedge 7,2 kg
Технические характеристики
CharacteristicsApplicationsprecisionOther characteristicsadjustable, with screw on bolt
