Installation: outdoor Highest voltage for equipment Um (r.m.s.) 12 up to 36kV Rated power-frequency withstand (induced) voltage (r.m.s.): 75kV Rated lightning impulse withstand voltage (peak): 175kV Rated frequency: 50Hz or 60Hz Applied standard: IEC 61869-1&3 (IEC 60044-2) Specifications: Epoxy resin casting and full-closed construction, single-pole for phase to ground connection, It is widely used for measuring voltage, electric energy and protective relaying in the sing-phase or three phase power system with the frequency 50Hz or 60Hz and highest voltage for equipment up to 36kV.
Технические характеристики
CharacteristicsTypepowerApplicationsfor outdoor serviceElectrical characteristicssingle-phaseMountingpole-mountedNormsIECOther characteristicsepoxy resinPrimary voltage
30 kV, 33 kV, 34.5 kV, 35 kV
Secondary voltage
Min.: 100 V
Max.: 240 V
110 V, 115 V, 120 V, 220 V
Frequency
50 Hz, 60 Hz
