The SAC Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events. Features: Glass passivated chip junction in DO-15 Package 500W peak pulse power capability at 10×1000μs waveform, repetition rate (duty cycles):0.01% Fast response time: typically less than 1.0ps from 0 Volts to BV min Typical failure mode is short from over-specified voltage or current Whisker test is conducted based on JEDECJESD201A per its table 4a and 4c IEC-61000-4-2 ESD 15kV(Air), 8kV (Contact) ESD protection of data lines in accordance with IEC 61000-4-2 (IEC801-2) EFT protection of data lines in accordance with IEC 61000-4-4 (IEC801-4) Low incremental surge resistance High temperature soldering guaranteed: 260°C/40 seconds / 0.375”,(9.5mm) lead length, 5 lbs., (2.3kg) tension Plastic package has underwriters laboratory flammability classification 94V-O Matte tin lead–free plated Ideal for data line applications Halogen free and R
Технические характеристики
CharacteristicsTechnologyTVSMountingaxial-leadFunctionpowerDC voltage
Max.: 88 V
Min.: 10 V
Reverse voltage
Max.: 50 V
Min.: 5 V
