Kitagawa’s leading power chuck can be used with both hard and soft jaws. Chucks are manufactured from high grade alloy steel. Three jaw wedge style power chucks deliver up to 20% more speed, gripping force and bore size when compared to conventional chucks. Jaw Stroke (diameter mm): 5.5 Plunger Stroke (mm): 12 Weight (with soft jaws) 11.9kg Moment of inertia: 0.058 kg.m2 Matching cylinder: S1246 Max pressure: 2.8 MPa, 28.6 cm2 Matching hard top jaw: HB06B1 Matching soft top jaw: SB06L1A Mounting: Recess mount, requires additional adaptor. Standard Equipment: Chuck includes mounting bolts, T-nuts and jaw mounting bolts. Also included blank drawnut and mounting wrench.
Технические характеристики
CharacteristicsTypeautomaticNumber of jaws3-jawOther characteristicsthrough-hole, alloy, steelRotational speed
Max.: 6,000 rpm (37,699.11 rad.min-1)
Min.: 0 rpm (0 rad.min-1)
Gripping force
Max.: 57 kN
Min.: 0 kN
Outer diameter
Max.: 169 mm (7 in)
Min.: 20 mm (1 in)
