Product Information
Accurate
- Certificate of Calibration showing traceability to PTB included with every gage
- Matching Calibration Standards and Procedures available for every model
- Highly wear resistant Carbide Probe for longest life and continuous accuracy
- Remove center of dial cover for easy calibration adjustment
- Conforms to national and international standards
Durable
- Extra rugged housing, not affected by mechanical shock, water, acid or solvents
- Unique overall design, fully supported, positive positioning, no pivoting tendencies during measurement
- Can be used fully supported or with only the front probe area contacting the surface
- Functions on a permanent rare-earth cobalt magnet
- No batteries/electronics
- 2 year warranty
Easy To Use
- Positive visual and audible indicators to designate when
thickness reading is established - “V” grooves in probe housing and Gage base allow correct
positioning on cylindrical objects - Compact, lightweight, precisely balanced, independent of
gravity – can be used in any position - GO/NO-GO button can be pre-set for rapid measurement
- Probe contact and dial rotation all in a one-finger operation
- Furnished with wrist strap and instructions in a high quality
leather case with belt loops for your convenience
Four Models (FM, F, GM, G) For: Hot dip galvanizing, hard chrome metalizing, paint, enamel, plastic coatings on steel. Scale FM 0-80 mils Tolerance: ±0.2 mils up to 4 mils
±5% of the reading over 4 mils For: Electroplating, thin paint films,
phosphating on steel. Scale GM 0-8 mils Tolerance: ±0.04 mils up to 0.8 mils
±5% of the reading over 0.8 mils Scale F 0-2000 µm Tolerance: ±5 µm up to 100 µm
±5% of the reading over 100 µm Scale G 0-200 µm Tolerance: ±1 µm up to 20 µm
±5% of the reading over 20 µm
