Directional seated valves are a type of directional valve. As ball valves they have zero leakage in the closed state. A hand lever operates the eccentric shaft that controls the plunger for opening or closing the valve seats. The actuation is undertaken via the hand lever with automatic centring in the neutral position or with a notch. The directional seated valve type VH is suitable for pipe connection. The directional seated valve bank type VHR comprises several valves of type VH that have been clamped together connected in parallel via a tension rod to form a valve bank. The directional seated valve type VHP is available as a manifold mounting valve. Features and benefits: Actuation using hand lever with automatic centring in zero position or with notch Different arrangements in valve bank possible Leakage-free seated valve technology Intended applications: Construction and construction materials machinery Offshore and marine technology Process engineering systems Oil hydraulics and pneumatics
Технические характеристики
CharacteristicsTypepoppetActuating methodlever-operatedOperating pressure
500 bar, 700 bar (7,252 psi)
Flow rate
12 l/min, 25 l/min (3 us gal/min)
