Directional seated valves are a type of directional valve. As ball valves they have zero leakage in the closed state. The directional seated valve type G, WG, H, P, K, T and D is available as a 2/2, 3/2, 4/2, 3/3 and 4/3 directional seated valve with different actuation types. Actuation using a hand lever enables switchable pressures of up to 700 bar. Appropriate connection blocks enable direct pipe connection. The directional seated valves are available in a combination of valves in valve bank type VB. Features and benefits: Zero-leakage ball valve construction with high switching reliability Solenoid, pressure, mechanical or manual actuation Low shifting forces and gentle, smooth switching Intended applications: Machine tools (cutting and non-cutting) Clamping equipment, punching tools, jigs Rubber and plastics machinery Oil hydraulics and pneumatics Hydraulic tools
Технические характеристики
CharacteristicsTypepoppetActuating methodlever-operated, mechanically-operatedPorts/positions4/3-way, 4/2-way, 3/2-way, 2/2-wayOperating pressure
400 bar, 500 bar, 700 bar (5,802 psi)
Flow rate
Min.: 6 l/min (2 us gal/min)
Max.: 65 l/min (17 us gal/min)
