The 10RP22-05 Dual Wavelength Multiple-Order Half Wave Plate is a crystal quartz optic designed to differentially retard the phase of a polarized beam. With the proper phase shift, this wave plate can rotate the direction of polarization or convert linear into circular polarization. This 532 and 1064 nm antireflection coated 1 inch (25.4 mm) diameter multiple-order wave plate has &lambda,/2 (180) retardation. When using multiple-order wave plates, several items should be considered. A waveplate of practical thickness produces a multiple of &lambda,/4 or &lambda,/2 retardation (i.e. 15 1/2 &lambda, for about 1 mm thickness). Higher orders cause retardation to vary dramatically with wavelength. Wave plates are sensitive to temperature changes. A typical multiple-order wave plate has a temperature coefficient of 0.0015&lambda,/C, compared to 0.0001&lambda,/C for a zero-order wave plate, so tighter temperature control will be required. Precise adjustment of retardation is possible by tilting the wave plate. Tilting about the slow axis increases retardation, while tilting about the fast axis reduces retardation.
Технические характеристики
- Diameter 25.4 mm
- Material Quartz
- Construction Single plate
- Wavelength Range 532 & 1064 nm
- Retardation &lambda,/2
- Retardation Accuracy ±&lambda,/300
- Damage Threshold 2 MW/cm2 CW, 2 J/cm2 with 10 nsec pulses, typical
- Wavefront Distortion &le,&lambda,/10 at 632.8 nm over the full aperture
- Surface Quality 10-5 scratch-dig
- Reflectivity per Surface Ravg
- Clear Aperture 22.8 mm
- Diameter Tolerance +0/-0.25 mm
- Wedge
- Cleaning See How to Clean Optics
