Полные гибкие стальные правила

Полностью гибкие стальные линейки Mitutoyo обеспечивают высокоточные измерения длины и других линейных измерений на полностью гибкой стальной линейке.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

The Mitutoyo Full Flexible Steel Rules are constructed with tempered stainless steel to ensure accuracy of length measurements and provide better durability for a longer instrument life span. The clear graduations on the satin-chrome finish assists with measurement reading.

Available in many different sizes, graduations and widths
Graduations are easy to read
Full-flexible rules are 1/64” thick
Constructed of tempered stainless steel

Order No.:	Product Image:	Size:	Graduation:	Width:	Accuracy:

Order No.:

182-141	—	18”(4R)	1/8 1/16 1/32 1/64	3/4”	+.006 / -.0035″ / +0.15 / -0.09mm
182-201	—	6”(4R)	1/8 1/16 1/32 1/64th	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-202	—	6”(16R)	1/32 1/64 1/50 1/100th	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-203	—	6”(5R)	1/32 1/64 1/10 1/100th	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-204	—	6”(3R)	1/32 1/64 1/10 1/50th	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-205	—	6” x 150mm	1/32 1/64 1mm 0.5mm	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-206	—	6” x 150mm	1/50 1/100 1mm 0.5mm	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-207	—	6” x 150mm	1/10 1/100 1mm 0.5mm	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-208	—	6” x 150mm	1/10 1/50 1mm 0.5mm	1/2”	+.004 / –.0035″ / +0.1 / –0.09mm
182-211	—	150mm	1mm 0.5mm 1mm 0.5mm	12mm	+.005 / –.0035″ / +0.13 / –0.09mm
182-221	—	12”(4R)	1/8 1/16 1/32 1/64th	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-222	—	12”(16R)	1/32 1/64 1/50 1/100th	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-223		12”(5R)	1/32 1/64 1/10 1/100th	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-224	—	12”(3R)	1/32 1/64 1/10 1/50th	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-225	—	12” x 300mm	1/32 1/64 1mm 0.5mm	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-226	—	12” x 300mm	1/50 1/100 1mm 0.5mm	1/2”	+.005 / –.0035″ / +0.13 / –0.09mm
182-231	—	300mm	1mm 0.5mm 1mm 0.5mm	12mm	+.005 / –.0035″ / +0.13 / –0.09mm
182-242	—	18”(16R)	1/32 1/64 1/50 1/100th	3/4”	+.006 / -.0035″ / +0.15 / -0.09mm
182-243	—	18”(5R)	1/32 1/64 1/10 1/100th	3/4”	+.006 / -.0035″ / +0.15 / -0.09mm
182-245	—	18” x 450mm	1/32 1/64 1mm 0.5mm	3/4”	+.006 / -.0035″ / +0.15 / -0.09mm
182-251	—	450mm	1mm 0.5mm 1mm 0.5mm	18mm	+.006 / -.0035″ / +0.15 / -0.09mm
182-261	—	24”(4R)	1/8 1/16 1/32 1/64	3/4”	+.007 / –.0035″ / +0.18 / –0.09mm
182-262	—	24”(16R)	1/32 1/64 1/50 1/100th	3/4”	+.007 / –.0035″ / +0.18 / –0.09mm
182-263	—	24”(5R)	1/32 1/64 1/10 1/100th	3/4”	+.007 / –.0035″ / +0.18 / –0.09mm
182-265	—	24” x 600mm	1/32 1/64 1mm 0.5mm	3/4”	+.007 / –.0035″ / +0.18 / –0.09mm
182-271	—	600mm	1mm 0.5mm 1mm 0.5mm	18mm	+.007 / –.0035″ / +0.18 / –0.09mm

182-141
182-201
182-202
182-203
182-204
182-205
182-206
182-207
182-208
182-211
182-221
182-222
182-223
182-224
182-225
182-226
182-231
182-242
182-243
182-245
182-251
182-261
182-262
182-263
182-265
182-271

Полные гибкие стальные правила

Технические характеристики
