Operating principle — Reflection principle Application — Detection of bottle container Detection of semi-transparent media Detection of transparent films Operating range — 0.03 … 4.5 m, With reflector TK(S) 100×100 Operating range limit — 0.03 … 6 m, With reflector TK(S) 100×100 Light source — LED, Red Protective circuit — Polarity reversal protection Short circuit protected Supply voltage UB — 10 … 30 V, DC, Incl. residual ripple Residual ripple — 0 … 15 %, From UB Open-circuit current — 0 … 20 mA Number of digital switching outputs — 1 Piece(s) Switching element — Transistor, PNP Switching principle — Dark switching (light switching by reversing polarity of UB) Switching frequency — 500 Hz Response time — 1 ms Type of connection — Connector Thread size — M8 Material — Plastic No. of pins — 4 -pin Dimension (W x H x L) — 11 mm x 32.4 mm x 20 mm Housing material — Plastic Plastic housing — PC-ABS Lens cover material — Plastic Net weight — g Type of fastening — Two M3 threaded sleeves Via optional mounting device Compatibility of materials — ECOLAB Operational controls — 270° potentiometer Ambient temperature, operation — -40 … 60 °C Degree of protection — IP 67 Protection class — III Certifications — c UL US Standards applied — IEC 60947-5-2
Технические характеристики
CharacteristicsSensing modepolarized retroreflectiveHousingrectangularType of beamLED, red lightOther characteristicsplastic, digital, IP67Maximum range
Max.: 4.5 m (1409)
Min.: 0 m (000)
