Product Information Benefits
Highly Versatile Tool
- Perfectly suited for long seam weld inspection on flat specimen or pipe, and for corrosion mapping
- Easy to deploy and able to encode in raster scan across long distances, providing C-Scan mapping of large composite parts
- Quick & efficient solution for the assessment of damaged or freshly repaired CFRP surfaces
Innovative Design
- Two integrated encoders, 2D scanning precision
- Non marring wheels with integrated magnets, Safe to use on composite, asy to use on steel
- Brake that locks the location of the scanner at the desired position
- Individual probe suspension that can be fixed axially or laterally
- Can support up to two Phased Array (PA) probes at the same time, Compatible with most Phased Array wedges
Specifications Pipe Range, Circumferential 4″» NPS (4.5″») to flat Pipe Range, Longitudinal 4″» NPS (4.5″») to flat Radial Clearance 48mm (1.9) on a 4 NPS pipe, 70mm (2.8) on plane surface Probe Holding Capacity 2 phased array probes with option PA Probe Holder Minimum Wedge Width 15.6mm (0.61) PA Probe Holder Maximum Wedge Width 75.6mm (2.98) Umbilical Length 3m (10) Cart Height 70mm (2.75) Cart Width 146mm (5.75) Cart Length 144mm (without probe) (5.67) Cart Weight 1.2kg (2.7lbs) Operating Temperature -20°C (-4°F) to 50°C (122°F) Environmental Sealing Submersible
Specifications listed may change without prior notification.
