PNEUMATIC MOTOR PUMP Ratio 4:1 – 38 l.p.m. application: direct priming for high viscosity products use: transfer PRESTAZIONI: Air Inlet Pressure Range — 2- 6 bar Ratio — 4:1 B Max Rec’d Cycles / Minute — 70 Displacement Per Cycle — 630 cc Flow @ 70 Cycles / Minute — 38 l.p.m. Air consumption @ 6 bar — 1300 N.l.p.m. SPECIFICHE: Lower Pump Material — Stainless Steel Pumping stem material — Stainless Steel Hard Chrome opt. 316 SS High Density Ceramic Coated Cylinder Material — 316 L Stainless Steel Seal set — Teflon/Carbographite spec. compound Air Motor — 2012 Motor Diameter — 125 mm Stroke — 125 mm Multistage silencer — 2202-35 – Stainless steel Air Inlet — G 3/8″ (M) Material Inlet — Direct priming Material Outlet — G 1″ (M) Weight — 54 kgs ACCESSORI: Air FR+L — 3822-CA Pneumatic elevator — 210722-1/2 Mounting brackets — 210703 Delivery filters — 96430, 97140
Технические характеристики
CharacteristicsOperationpneumaticPrimingself-primingMobilitystationaryDomainindustrialApplicationstransferMaterialstainless steelFluid specificationfor high-viscosity fluidsOther characteristicswith sealFlow
38 l/min (10.03854 us gal/min)
Pressure
Max.: 6 bar (87.023 psi)
Min.: 2 bar (29.008 psi)
Output diameter
1 in
Weight
54 kg (119.05 lb)
