Working Stroke [mm]: — 0 Throat [mm] A1: — 80 Troat [mm] A2: — 0 T-slot [mm] similar to DIN 650: — 12 Ram bore Øxdepth [mm]: — 20H7 x 25 Ram Ø [mm] / Surface F [mm²]: — 40 Space required CxG [mm]: — 155 x 220
Технические характеристики
CharacteristicsOperationpneumaticFunctionformingStructuretoggle, ramForce
13 kN
Stroke
Max.: 120 mm (5 in)
Min.: 40 mm (2 in)
Table width
115 mm (5 in)
Table length
157 mm (6 in)
Weight
40 kg (88 lb)
