Tantec’s New SpinTEC Atmospheric Plasma treatment system is built around the concept of a high voltage DC Plasma discharge in atmospheric air. The versatility of this unit allows for use in fully integrated robotic cells, as a standalone unit, or most any production line. SpinTEC possesses an AC motor for spinning 2 pcs. of PlasmaTEC-X nozzles pointing inwards for uniform treatment and to minimize heat impact. The treatment area can be between 40-150mm. SpinTEC connects to standard generator PLX and standard PlasmaREMOTE. The system is able to rotate up to 1000 rpm / min., and it is possible to treat up to 10 m/min. To ensure proper Plasma Discharge from the Discharge Nozzle the compressed air must be within a certain level of pressure and volume, the new AirTEC system, which is built into the PlasmaTEC-X ensures a constant flow to the Discharge Nozzle at all times. Easy to use The system must be connected to mains power and compressed air, no adjustment of air or power is necessary. Potential free discharge Allows treatment of both conductive, non-conductive as well as semiconductive surfaces. High-speed treatment High power impact enables treatment times up to 10 m/min., depending on the material. Control signals A large number of various signals are available on a digital interface to control and monitor the Plasma discharge at all times. Automatic discharge air regulation No matter the length of the power/air cable, the generator will adjust automatically to ensure the correct air pressure and flow.
Технические характеристики
CharacteristicsTypeplasmaOther characteristicsautomatic, atmospheric
