Planer type boring and milling center TX-S seriesCNCverticaluniversal

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Артикул: TX-S series TME арт.: TX-S series

High rigidity and precision thanks to its thermo-symmetrical structure. It stands out for its reliability and unbeatable performance. The TX series is one of the most recognisable symbols in the JUARISTI universe. We have a long track record of designing this type of solutions, which over the years have become one of the most sought after by our customers. This machine can successfully carry out boring and milling operations. Thermo-symmetric design with central head. Oversized cast iron structural components. Hydrostatic rotary table with double pinion system to eliminate blacklash. High-precision and high-rigidity linear guides. Multiple customisation and automation options. STRUCTURAL ELEMENTS Oversized cast iron structure. Minimal thermal deformation ensured thanks to the thermo-symmetric column with centred head. Optimal head guiding and efficient force distribution. High-precision bearings. Vertical travel up to 2,500 mm (TX1), 3,000 (TX3) and 4,000 mm (TX7). HEADS AND TABLES AOD Universal spindle 1° x 1° | 0.001° x 0.001° | 40 kW | 6,000 min-1 | 60 kW | 3,000 Nm. AOD Orthogonal head 1ºx1º | 40 kW | 5000 min-1. Compact vertical head ISO 50 1º x 1º. Adaptable with boring bar, diameter 110-130 mm (TX1), 130-150 mm (TX3) and 150-180 mm (TX7). Hydrostatic rotary table with capacity from 8 ton (TX1) to 60 ton (TX7). Wide workspace of 1,600 x 2,000 mm (TX1), 2,000 x 2,500 mm (TX3) and 3,000 x 2,500 mm (TX7). Thermal sensors for real-time temperature monitoring.

Технические характеристики

CharacteristicsControl typeCNCSpindle orientationvertical, universalApplicationsfor aerospace applications, for moldsOther characteristicsrotating table, high-precision, high-rigidity, hydrostatic, planer type, desk, 4-axis, column typeX travel

2,000 mm, 3,000 mm, 4,000 mm, 5,000 mm, 6,000 mm (79 in)

Y travel

Max.: 4,000 mm (157 in)

Min.: 1,500 mm (59 in)

Z travel

1,500 mm, 2,000 mm, 2,500 mm, 3,000 mm (59 in)

W travel (spindle)

600 mm, 800 mm, 1,000 mm (24 in)

Spindle diameter

Max.: 180 mm (7 in)

Min.: 110 mm (4 in)

Power
