The load-holding valve type CLHV is suitable for applications with low and medium tendencies to oscillate and is used especially in connection with proportional directional spool valves, e.g. types PSL and PSV. It is also available with return pressure compensation and spring chamber relief. As a screw-in valve, type CLHV-C can either be installed at the manifold, in the pipe, or directly at the cylinder or hydraulic motor. Type CLHV-PIB can either be installed in the pipe or directly at the cylinder or hydraulic motor.
Технические характеристики
CharacteristicsTypepistonOperationhydraulically-operatedFunctionpressure-controlBodyscrew-in, manifold, mediumApplicationsfor motors, for cylindersAssociated functionbalancing, loadOther characteristicsproportionalPressure
350 bar (5,076.3 psi)
Temperature
Max.: 80 °C (176 °F)
Min.: -40 °C (-40 °F)
Flow rate
30 l/min, 75 l/min, 150 l/min, 320 l/min (7.93 us gal/min)
