The IMTG has been designed for use in continuous submersion in liquids such as water, oils and fuels in small tanks and containers where conventional mechanical level switches and sensors are not ideal and more level ‘control’ and measurement is required. The IMTG submersible device uses a silicon pressure sensor which has excellent performance and stability. It is ideal for applications where a small tank level is required from as low as 1m through to 10m high tanks. The housing is stainless steel and with a choice of PUR or FEP cable material enables compatibility to water, oils and fuels. Every device is temperature compensated and calibrated, supplied with a traceable serial number and calibration certificate. • Pressure ranges from 1mWG to 10mWG • Accuracy:
Технические характеристики
CharacteristicsTechnologypiezoresistiveMediumfor water, for oil, for fuelInterface4-20 mA, 2-wireApplicationsfor small tanksOther characteristicsstainless steel, submersibleLevel range
Max.: 10 m (3209)
Min.: 1 m (303)
Process temperature
Max.: 75 °C (167 °F)
Min.: -20 °C (-4 °F)
