1.) Advanced functionalities Philips GS20 monitor provides real-time data on cardiac and respiratory conditions in order to fit different clinical settings. As well as specific monitoring parameters such as Philips ST / AR 3-and5-lead ECG/ respiration, NBP, 2 temperatures, and Philips SpO2/PR, ST and arrhythmia monitoring, it also offers options for 2-channel intrusive blood pressure and Microstream etCO2 monitoring. 2.) Ease of use GS20 patient monitor has a 12.1 “display with flexible display modes such as large number display, minitrend, OxyCRG, and the height adjustment function of the auto waveform channel to fit different clinical settings. For maximum ease of use, intuitive menus, fixed key access, bright color screen, and optional touchscreen have all been designed. 3.) Networking and data management The G40E comes standard with LAN networking capabilities for facilities that seek to create a bi-directional communication network with a central monitoring system from Philips Efficia CMS200 or require data output in HL7 format. 4.) Compact and cost-effective The G40E patient monitor, designed in compliance with Philips ‘ exacting quality standards, offers market-proven critical parameters in a lightweight, cost-effective display to produce precise measurement results on your tight budget. The role of an alarm clock helps to reduce alarm fatigue in order to create a quiet care environment. 5.) Works with Efficia consumables The G40E patient monitor is designed to be compatible with consumables from Philips Efficia, which are also used on patient monitors from the Philips Efficia CM series, to reduce your total cost of ownership by sharing consumables from Philips across various care settings. Specifications ECG Lead type 3-lead or 5-lead selectable Lead selection, 3-lead I, II, III Lead selection, 5-lead I, II, III, aVR, aVL, aVF, V HR measurement Adult / pediatric: 15 bpm – 300 bpm Neonatal: 15 bpm – 300 bpm Step: 1 bpm HR accuracy ±5 bpm or ±1 %, whichever is greater Arrhythmia 21 calls ST measurement range -2.5 mV – +2.5 mV Waveform speed 6.25 mm/s,12.5 mm/s, 25 mm/s, 50 mm/s Gain selection x 1/4, x 1/2, x 1, x 2, x 4, Auto Pacemaker detection Yes Protection Against electrosurgical interference and defibrillation Non-invasive blood pressure (NBP) Method Automatic oscillometric Parameters SYS/DIA/MAP/Pulse Rate Operating mode Manual/Auto/STAT Auto measure intervals 3, 5, 10, 15, 30, 60, 90, 120, 240, 480 minutes Units mmHg/kPa Cuff pressure range, adult / pediatric 0 – 300 mmHg ( 0 kPa – 40.0 kPa) Cuff pressure range, neonate 0 – 150 mmHg ( 0 kPa – 20.0 kPa) Systolic measurement range, adult/ pediatric 30 mmHg – 254 mmHg (4.0 kPa – 33.9 kPa) Systolic measurement range, neonate 30 mmHg – 135 mmHg (4.0 kPa – 18.0 kPa) Diastolic measurement range, adult / pediatric 10 mmHg – 220 mmHg (1.3 kPa – 29.3 kPa) Diastolic measurement range, neonate 10 mmHg – 110 mmHg (1.3 kPa – 14.7 kPa) MAP measurement range, adult / pediatric 20 mmHg – 235 mmHg (2.7 kPa – 31.3 kPa) MAP measurement range, neonate 20 mmHg – 125mmHg (2.7 kPa – 16.7kPa) Accuracy, maximum standard deviation 8 mmHg (1.1 kPa) Accuracy, mean error ±5 mmHg (±0.7 kPa) Pulse rate range 40 bpm – 240 bpm Pulse rate accuracy ±5bpm or ±5%, whichever is greater SpO2 (Philips SpO2 technology) Measurement range 0 – 100 % Accuracy 70 % – 100 %, depends on sensor, 0 – 69 %, unspecified Waveform speed 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s Pulse rate range 30 bpm – 300 bpm Pulse rate accuracy ±2 bpm or ±2%, whichever is greater Perfusion index Yes Respiration (RESP) Measurement method Thoracic impedance Measurement range 0 rpm – 150 rpm Accuracy 0rpm – 120rpm: ±1 rpm, 121rpm – 150rpm: ±2 rpm Waveform speed 6.25 mm/s,12.5 mm/s, 25 mm/s, 50 mm/s Accuracy undefined Gain selection x 1/2, x 1, x 2 Apnea alarm Yes, 10 – 60 s Work mode Auto or manual (threshold) RESP lead RA-LL Temperature (TEMP, 2-channel) Measurement range 0 – 50℃ (32℉ – 122℉) Resolution 0.1℃ (0.2℉) Accuracy ±0.1℃ (±0.2℉) (without sensor) Units ℃ / ℉ Minimum measuring time Attachable skin surface probe: less than 10 minutes Esophageal/rectal probe: less than 2 minutes Capnopgraphy (etCO2, optional) Method Microstream, infrared absorption (Oridion) Parameters awRR, etCO₂, inCO₂ Measurement range 0 – 99 mmHg (0 kPa – 13.2 kPa) Accuracy+C781, 0 – 38 mmHg (0 kPa – 5.1 kPa) ±2 mmHg (±0.28 kPa) Accuracy, 39 mmHg – 99 mmHg (5.2 kPa – 13.2 kPa) ± (5% of reading + 0.08% for every 1 mmHg (0.13 kPa) above 38 mmHg (5.1kPa) awRR range 0-150 rpm awRR accuracy, 3 rpm – 70 rpm ±1 rpm awRR accuracy, 71 rpm – 120 rpm ±2 rpm awRR accuracy, 121 rpm – 150 rpm ±3 rpm Invasive Blood Pressure Accuracy ±4 mmHg (0.53 kPa) or ±4 % of reading, whichever is greater Invasive blood pressure (IBP, 2-channel, optional) Parameters SYS/DIA/MAP/Pulse Rate Measurement range -50 – 400 mmHg (-6.6 kPa – 53.3 kPa) Waveform speed 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s Resolution 1 mmHg (0.13 kPa) Units mmHg/kPa/cmH₂O Transducer sensitivity 5 uV/V/mmHg Pulse rate range 30 bpm – 254 bpm Pulse rate accuracy ±2bpm or ±2%, whichever is greater Sampling rate 62.5 samples per second Recorder (optional) Type Built-in thermal recorder, 3 channels Print mode Real-time recording, timed recording, alarm-activated recording Print speed Auto, 12.5 mm/s, 25 mm/s, 50 mm/s Display Type Color TFT LCD, 4:3 Size 10.4+611:631″ Resolution 800 x 600 pixels Channels Max 11 channels (auto waveform channel height adjustment) Power supply AC power input 100 – 240 VAC, 50/60 Hz Battery Rechargeable Li-Ion battery Maximum 2.5-hour continuous monitoring (1 battery) Weight and dimensions Net weight Approx. 3.5 kg without battery Dimensions (w x d x h) 316 mm x 265 mm x 131 mm (12.5 in. x 10.5 in. x 5.2 in.) Safety approval and quality system Safety standard IEC 60601-1-2:2014 Electromagnetic environment IEC 60601-1-2:2000/A1:2014 Quality system ISO9001 & ISO13485 certified CE marking according to the Council Directive 93/42/EEC Waterproof IPX1 Data review and storage Data review and storage 1600- NBP data, 1200 hr trend graph, 120 min full disclosure ECG 1, 200 – alarm & arrhythmia events External interface (standard) External interface ECG analog output VGA output Nurse call LAN USB Cardiac Output (optional) Measurement method Right heart thermodilution Measurement range 0.1 l/min – 20.0 l/min Measurement accuracy ±0.2 l/min or ±10 %, whichever is greater Blood temperature range 27℃ – 43℃ (80.6℉ – 109.4℉) Blood temperature accuracy ± 0.1℃ Injection temperature 0℃ – 27℃ (32℉ – 80.6℉) List of Supply with Patient Monitor: Name of accessoriesQuantityECG Cable 1SpO2 Sensor1NIBP Cuff (Adult) with cable1Power Cable1User Manual1 Estimated Delivery: 5-7Days Warranty :
- 1 Years
Product Specifications Color: White Optional Items / Parameters: EtCO2, Recorder, Cardiac Output Parameters: ECG, RESP, SpO2, PR, NIBP and TEMP Brand/Manufacturer Brand: Philips Display and User Interface Screen Size :
- 10 Inch
