This standalone data logger measures and stores more than 32,000 temperature readings over a -20 to +60°C range with a resolution of 0.1°C. The polycarbonate window and stainless steel 316 assembly provides protection from corrosion, impact and water ingress to IP67/NEMA 4X. The data logger is powered by a Lithium-Ion battery which can typically allow for logging for up to 1 month.
The user can easily set up the logger and view downloaded data by connecting the data logger to a PC»s USB port and using the free EasyLog software. Data can then be graphed, printed and exported to other applications for detailed analysis.
Features:
- 20 to +60°C (-4 to +140°F) measurement range
- Stores over 32,000 readings
- EasyLog software available as a free download
- Stainless steel (316 grade) case
- Rechargeable Lithium-Ion battery
- Logging rates between 1 second and 12 hours
- Immediate and delayed logging start
- User-programmable alarm thresholds
- Red & green status LEDs behind protective glass window
- Environmental protection to IP67
- Included: Type A — Mini B USB Cable
Specifications:
Model EEL-USB-1-RCG
Range -20 to +60°C
Resolution
0.1°C
Accuracy ±1°C
Logging Rate
User selectable between 1 second & 12 hours
Operating Temperature Range
-20 to +60°C
Battery Life
4 weeks (@ 20°C, 1 minute logging rate)
Recharging Time 5hrs Charging Temperature Range
+10 to +30°C
Readings
32,510
Dimensions 93 x 20mm
