The PE42724 is a HaRP™ technology-enhanced reflective SPDT RF switch designed for use in cable applications including DOCSIS 3.0/1 cable modem, set-top box and residential gateway. It delivers high linearity, excellent harmonics performance and high surge immunity in the 5–1794 MHz band. It also features low insertion loss and high isolation performance making the PE42724 ideal for DOCSIS 3.1 applications.
Технические характеристики
| Part Number: PE42724 |
| Manufacturer: pSemi |
| Type >,>,RF Switch: Single Pole |
| Function: SPDT (R) |
| Impedance: 75 Ohms |
| Frequency Range Min: 5 MHz |
| Frequency Range Max: 1794 MHz |
| Insertion Loss Min: 0.1 dB |
| Insertion Loss Max: 0.4 dB |
| Isolation Min: 19 dB |
| Isolation Max: 39 dB |
| Power Rating: 38 dBm |
| IIP3: 84 dBm |
| Package: 12L QFN |
| Description: High Linearity |
